50′ SHAMAN



The 50’ Apache® Shaman is the largest, most powerful and most elegant Apache® ever offered. It seems supernatural in the way it transforms the harshest offshore environment into a pleasurable experience, offering a stable and secure ride through even the roughest sea conditions. It features stand-up or sit-down flexibility for an amazing 9 occupants, including an elegant cabin arrangement with a full galley, enclosed head, various entertainment options and v-berth. Whether you are cruising the Keys or the Mediterranean, the Shaman is the tribal leader of Apache® Powerboats and, like all McManus creations, it can’t be duplicated.

50′ SHAMAN

  • LOA: 50′ 6″ (15.39 m)
  • Beam: 8′ 2″ (2.48 m)
  • Fuel: 450 gal., 5 tanks (1702.9 L)
  • Draft – Stern Drive Down: 54″ (137.16 cm)

SPECIFICATIONS AND FEATURES ENGINE OPTIONS

  • Teague Custom Marine or Mercury Marine available upon request.

(Twin or Triple engine configurations are available.)

CONSTRUCTION FEATURES

  • Hand laid composite; 100% Kevlar49 with vinylester resin; McManus custom weave design and lamination schedule with high density coring
  • 3-year hull warranty
  • Hull and deck Kevlar bonded together

STANDARD EQUIPMENT

  • Battery box: heavy-duty billet Optima aluminum powder coated (3)
  • Bilge blowers: 3” Flexmount (3)
  • Bilge pumps: Rule 2000, submersible (3)
  • Dash panels: aluminum, anodized, polished and laser engraved
  • Engine hatch: automatic
  • Engine race mounts: Mercury Racing, steel, front and rear (3)
  • Engine room light: Halogen (3)
  • Engine room: primed in gelcoat and finished in Awlgrip
  • Engine tie-bar: 316 stainless steel; clevis joint; external
  • Fasteners: stainless steel grade 18-8 with self-locking nuts throughout
  • Fenders (6)
  • Fender hangers: stainless steel (6)
  • Fuel filters: Teague billet aluminum with water separators (3)
  • Fuel pumps: Aeromotive electric (3)
  • Fuel tanks: heavy-duty, baffled aluminum; foamed and bolted in position with stainless steel pickups (5)
  • Propellers: Mercury 4-blade, stainless steel (3)
  • Rub rail: 2 1/16” white neoprene with stainless steel insert
  • Sea strainers: heavy-duty cast stainless steel (3)
  • Silencer: stainless steel; air operated
  • Spare prop mounts (3)
  • Steering system: Latham Marine
  • Sun pad with Apache Powerboat logo
  • Throttles and shifts: Latham Marine
  • Tonneau cover for cockpit and engine room: custom designed and fitted Acralon
  • Transom: step notch with pad keel
  • Trim planes: Mercury 280 Sport K-Planes (1 set)
  • Water pickup: transom mounted, stainless steel, adjustable (3)

COCKPIT AND CABIN

  • Beverage holders
  • Bolsters: forward stand-up or sit-down bolsters; rear bolster/bench seat
  • Cabin carpet: removable
  • Cockpit carpet: removable
  • Cockpit flooring: marine grade rubber
  • Cockpit refrigerator: AC/DC
  • Cockpit seating area for 8-9 people
  • Electric outlet: 110 v.
  • Head: enclosed; stainless steel sink; electric toilet
  • Holding tank: 20 gal.
  • Galley: stainless steel sink, AC/DC refrigerator and storage
  • Hand rails: billet aluminum
  • Helm: centerline
  • Ice cooler: removable
  • Lighting: LED; cabin ceilings and cockpit courtesy; Airpax circuit breaker
  • Mirror
  • Stereo system: audio entertainment with cassette or CD player; acoustic speakers (6 total; 2 in cabin; 4 in cockpit)
  • Storage area for dock lines, anchor and fenders
  • Water tank (fresh) and pump; 20 gal.

MECHANICAL FUNCTION INSTRUMENTS

Autometer gauges with custom anodized and polished bezels:

Choice of white, silver or black face instruments.

  • Tachometer (3)
  • Hour Meter (3)
  • Oil Pressure (3)
  • Oil Temperature (3)
  • Fuel Pressure (3)
  • Fuel (tank tender, 5-tank system)
  • Water Temperature (3)
  • Trim Indicator for Outdrives & Trim Tabs
  • GPS Speedometer
  • Voltmeter (3)
  • Engine Warning System (3)
  • Detonation Meter (3)



DECK RIGGING

  • Cleats: stainless marine; recessed, stainless steel (8)
  • Deck rail: powder coated
  • Fuel fills: flush; stainless steel; 2” (5)

12 VOLT DC ELECTRIC

  • 12 v. power outlet
  • Batteries: Optima heavy-duty marine (3)
  • Battery charger: automatic, 30 amp with 50’ shore power cord
  • Parallel solenoid and battery distribution switches (3)
  • Terminals, lugs, butt splices and connectors: locking design, nylon insulated
  • Wiring and cable: marine grade (UL) tinned copper, specifically designed for marine racing environment; color coded wiring throughout (legend provided)

NAVIGATION AND SAFETY

  • Air horn: Watsco hand-held
  • Anchor: Fortress chock mounted aluminum with rubber coated chain and 100’ nylon double braided anchor line
  • Compass system: Raymarine electronic analog
  • Cushion: throwable, Type 4 Permafloat
  • Dock lines: nylon double braided; choice of color (8)
  • Fire extinguisher system: Fireboy FE-241, automatic discharge, engine room
  • Fire extinguisher: 1A-10BC hand-held with 13’ range, cockpit mounted (2)
  • Flare kit
  • Fog bell
  • Horn: Alpex 12 v.
  • Lights: LED international navigation
  • Vests: Lifeline type 3, high performance (6)
  • VHF marine radio
